Neste modulo voce vai aprender sobre a interface grafica do software, ferramentas de dimensionamento de esbocos, criacao, modelagem 3D dentre outros assuntos, clique para mais detalhes do conteudo. Interface grafica do programa; Contrucao de esbocos 2D: line, arc, fillet, split, offset, move, mirror, trim corner,rotate, scale, strech, circle, rectangle, extend to next; Relacoes entre esbocos: tangent, paralel, concentric, equal, horizontal/vertical, connect, rigid set, symmetric, collinear, connect; Ferramentas de dimensionamento de esbocos: smart dimesion, distance between, angular, cordinate dimension, angle between, symmetric diameter, alinhament; Ferramentas de modificacao grafica do programa: style, Increase PMI, Decrease PMI; Ferramentas de criacao e modelagem 3D: extrude, box, cutout, revolve, round, hole, treads, draft, thin wall, sweep, helicoidal, loft, normal, thinken, fillet weld, groove weld, solid sweep, cutout 3d; Ferramentas multi body: add body, enclousures, union, subtract, intersect, split, scale body; Relacoes entre modelos 3d: tangent, paralel, concentric, equal, horizontal/vertical, connect, rigid set, symmetric, collinear, connect, perpendicular; Padroes: circular, rectangular, along curve, mirror, fill patern; Ambiente de visualizacao: zoom area, fit, zoom, pan, refresh view, rotate, look at face, view styles. Ferramenta de Sketch: sketch, 3d sketch, component
